10 Hp Single Phase Baldor Electric Compressor

BALDOR brand single phase 10 HP heavy duty industrial air compressor electric motor.

This listing is for a brand new 10 horsepower, 230 volt, single phase heavy duty air compressor motor model number L1512T, this motor is 230 volt, 39 full load AMPS, 60 Hz, 215T Frame, 1 phase, 1 3/8" shaft, and 1725 RPM. This motor is specifically designed for use with air compressors to meet start up load/torque specifications. This motor can rotate in either direction. This can replace a higher rpm motor you will just have to use a larger pulley to make up the rpm's on your compressor. If you have any questions about this motor or if it will work as a replacement on your compressor feel free to contact us our contact information is below.

"THIS ITEM ONLY SHIPS TO THE CONTINENTAL 48 UNITED STATES"

This motor has its manufacturer's warranty - 1 year limited through your local baldor service station*

• Model Number: L1512T
• Description: 10HP Compressor Duty Motor
• Ship Weight: 137 lbs.

Specifications:

• SPEC. NUMBER: 37M319T923
• CATALOG NUMBER: L1512T
• AMPS: 39
• FL EFFICIENCY: 85.5
• ENCLOSURE: OPSB
• FRAME: 215T
• HERTZ: 60
• INSULATION CLASS: B
• RPM: 1725
• Horsepower: 10
• PHASE: 1
• POWER-FACTOR: 97
• RATING: 40C AMB-CONT
• SERVICE FACTOR: 1.00
• VOLTAGE: 230
